The Samsung AR12BSHGAWK/FA Wall-Mounted Split Inverter Air Conditioner offers energy-efficient cooling with a sleek design. With a 12,000 BTU cooling capacity, it is perfect for medium-sized rooms, ensuring fast and even cooling.

Freeze Wash

Maintain the optimum performance with the push of a button. Freeze Wash quickly freezes the Heat Exchanger and then defrosts the ice. So it is washed in water, which washes away dirt and 90%” of microorganisms*. Finally, it dries up any moisture left. And it alerts you when it is time for a clean**.

Specification

Capacity

• Capacity (Cooling, Btu/hr): 12011 Btu/hr
• Capacity (Cooling, Min – Max, Btu/hr): 4,299 ~ 12,966 Btu/hr
• Capacity (Cooling, kW): 3.52 kW
• Capacity (Cooling, Min – Max, kW): 1.26 ~ 3.8 kW

Energy Efficiency

• EER (Cooling, W/W): 3.06 W/W
• EER (Cooling, Btu/hW): 10.44 Btu/hW

Noise Level

• Noise Level (Indoor, High/Low, dBA): 38 / 21 dBA
• Noise Level (Outdoor, High/Low, dBA): 50 dBA

Electrical Data

• Power Source(Φ/V/Hz): 1 / 220-240~ / 50
• Power Consumption(Cooling, W): 1150 W
• Operating Current(Cooling, A): 7.5 A

Physical specification

• Gross Dimension (Indoor, WxHxD, ㎜*㎜*㎜): 880*290*375 mm
• Gross Dimension (Outdoor, WxHxD, ㎜*㎜*㎜): 844*622*353 mm
• Net Dimension (Indoor, WxHxD, ㎜*㎜*㎜): 820*299*215 mm
• Net Dimension (Outdoor, WxHxD, ㎜*㎜*㎜): 720*548*265 mm
• Gross Weight (Indoor, kg): 10.5 kg
• Gross Weight (Outdoor, kg): 27.9 kg
• Net Weight (Indoor, kg): 9.2 kg
• Net Weight (Outdoor, kg): 25.1 kg
• Loading Quantity (20/40/40Hft without Pipe): 96 / 197 / 232
• Loading Quantity (20/40/40Hft with Pipe): 92 / 192 / 228 (ACCE 60)90 / 192 / 216 (ACCE 80)

Technical Information

• Piping Length (Max, m): 15 m
• Piping Height (Max, m): 7 m
• SVC Valve (Liquid (ODxL)): 6.35
• SVC Valve (Gas (ODxL)): 9.52
• Moisture Removal (l/hr): 1.5 l/hr
• Air Circulation (Cooling, ㎥/min): 11.2 ㎥/min
• Refrigerant (Type): R410A
• Refrigerant (Charging, kg): 0.95 kg
• Refrigerant (Charging, tCO2e): 1.98 tCO2e
• Low Ambient (Cooling, ℃): 16~46 ℃
• Outdoor Unit (Compressor Type): BLDC
• Outdoor Unit (Anti-Corrosion Fin): Yes

Air Flow

• Air Direction Control (Up/Down): Auto
• Air Direction Control (Left/Right): Auto
• Air Flow Control Step (Cool/Fan): 5/4
• Auto Clean (Self Cleaning): Yes

Convenience

• Filter Cleaning Indicatior: Yes
• Indoor Temp. Display: Yes
• Display On/Off: Yes
• Beep On/Off: Yes
• 24-Hour Timer: Yes
• Auto Changeover: No
• Auto Restart: Yes

Operating Mode

• Fast Cool: Yes
• Good Sleep: Yes
• Dehumidification: Yes
• Fan Mode: Yes
• Quiet: Yes
